Accurate, reliable and easy to use temperature controller for homebrewing.
Features:
Plug and play design, easy to use;
Dual relay output, be able to connect with refrigeration and heating equipment at the same time;
Support reading with Centigrade or Fahrenheit unit;
Maximum output load: 1100W(110V);
Dual display window, be able to display measured temperature and set temperature at the same time;
Compressor delay protection for refrigeration control
High and low temperature alarms are available;
Over-temperature and sensor fault alarm
Temperature calibration;
Heating/Cooling differential function could be set separately for refrigeration and heating to protect temperature controller from violent change.
Specification
Temperature Control Range : -60~120 °C / -58~248 ° F
Temperature Resolution: 0.1 ° C / 0.1° F Temperature
Accuracy: ±1°C (-50 ~ 70°C) / ±1°F (-50 ~ 160° F)
Temperature Control Mode :On/Off Control, Heating and Cooling
Input Power: 100 ~240VAC, 50Hz/60Hz
Temperature Control Output: Max. 10A, 100V ~240V AC
Buzzer Alarm: High and Low Temperature Alarm
Dimension Body: 140x68x33mm (5.5x2.7x1.3inch)
Socket: 85x42x24mm(3.3x1.7x1inch)
Sensor Type: NTC sensor (Including)
Sensor Length: 2m / 6.56ft
Ambient Temperature: -30~ 75 ° C / -22~ 167 ° F
Storage Temperature: -20~ 60 ° C / -4~ 140 ° F
Humidity 20~85% (No Condensate)
Package Content:
1x ITC 308S Temperature Controller;
1x 6.65ft DC Cord NTC Sensor
1x Manual
